Capacitor Voltage Transformer 110kv 45kv

Get reliable 110kv 45kv Capacitor Voltage Transformers from our factory. High-quality, durable and efficient products for your electrical needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Tyd110/220 Type
Insulating Medium
Insulating Gas
Installation
Active Type
Magnetic Circuit Structure
Combined Type
Voltage Transformation Principle
Photoelectric Type
Voltage Level
35\66\110\220kv
Transport Package
Standard Export Wooden Case
Specification
As per drawing
Trademark
VILLE
Origin
China

Product Description

Introduction to Product
Capacitor voltage transformer series products are suitable for current, electric energy measurement and relay
protection in a system with effectively earthed neutral with rated voltage 35kV, 66kV, 110kV or 220kV and rated
frequency 50Hz. It can also be used for carrier wave communication concurrently.

This product consists of capacitor voltage divider and electromagnetic unit the medium voltage terminal and low
voltage terminal of capacitor voltage divider are lead out into an oil tank equipped with electromagnetic unit. The electromagnetic unit consists of middle transformer, a compensation reactor and a damper.

The capacitor voltage divider consists of a bushing, a core and a metal expander. The core of capacitor is
combined by several film-paper composite media and serial parts which are made by coiling aluminum foils, it is
carried out vacuum dipping treatment, the porcelain bushing is filled with transformer oil, and it is equipped with
the metal expander to compensate the change of oil volume at different temperatures.

This series transformer has a quick saturation damping device with a quick transient response speed, and it
also can damp ferroresonance reliably.

There is a carrier wave communication terminal in the secondary outlet box, and it also has an over-voltage
protection clearance.

There are an oil level gauge, an outlet box, a nameplate, an oil-discharge plug and an earthing base outside
the oil tank.

The sealing structure of product is optimized, so it has a good sealing performance.
Capacitor Voltage Transformer 110kv 45kv
Capacitor Voltage Transformer 110kv 45kv
Our Services

1.

Pre sale service

a.

make technical solution

b.

send quotation, technical data sheet and drawing

c.

prepare power transmission plan, testing plan and shipment plan

2.

In sale service

a.

supervise the manufacturing schedule totally in accordance with the plan

b.

send photos to customer during every manufacturing process(hold point)

c.

inform the customer one week before testing.

3.

After sale service

a.

installation and commissioning, training the workers

b.

quick response within 12 hours any time

c.

provide 12 months guarantee period normally.


FAQ

1. Q:

What is your delivery time ?

A:

Depend on the type of transformer.

2. Q:

What is your payment term?

A:

30% advance by T/T , 70% before delivery by T/T or L/C or we can discuss about it.

3. Q:

What kind of standard you follow?

A:

IEC, ANSI, CSA, GB, etc

4. Q:

What kind of supporting documentation you can provide normally

A:

Quotation, outline drawing, manufacturing plan, quality control plan
testing plan, financial report, type test report(KEMA, CESI),reference list, etc

5. Q:

What is your normal warranty period?

A:

12 months after transformer operation.

6. Q:

Can u do installation and commission in user's site?

A:

Yes, we can send our installation team to user's country for service.

7. Q:

Do you have any experience in this kind of transformer?

A:

Yes, we can provide reference list for check.
